Vision offers a range of premium profiles for commercial and domestic applications, designed to protect and inspire with variable mood accents. The range is specifically designed to accept universal LED systems and RGB for Steps, Listello, Edges and Skirting offering unlimited freedom of design.
Developed with simplicity in mind, the range of supporting hardware offers the most frequently installed systems with Polycarbonate Diffusers that eliminate the hotspots.
Nosing: Vision – Light Down (NALR50)
Commercial style stair nosing incorporating a range of non-slip PVC based inserts and Vision LED, CCT and RGB lighting systems in a ‘light down’ configuration. Supplied in anodised Matt Silver finish, others finishes are available on request. Standard length is 2.8m but we offer a bespoke cutting and drilling service if required and end caps to complete the professional aesthetic. Complete with frosted polycarbonate diffuser to ensure optimum light dispersion.
Nosing: Vision – Light Out (NSLR50)
Commercial style stair nosing incorporating a range of non-slip PVC based inserts and Vision LED, CCT and RGB lighting systems in a ‘light out’ configuration. Supplied in anodised Matt Silver finish, others finishes are available on request. Standard length is 2.8m but we offer a bespoke cutting and drilling service if required and end caps to complete the professional aesthetic. Complete with frosted polycarbonate diffuser to ensure optimum light dispersion.
Wall/Floor: Vision – MultiFix (TLD)
A versatile tile-in profile incorporating Vision LED, CCT and RGB lighting systems. Can be used in wall or floor installations to break up large expanses of tile or create a pathway in the flooring surface. Supplied in anodised Matt Silver finish with frosted polycarbonate diffuser for optimum light dispersion. Available in 10mm or 12mm heights and a standard length of 2.8m. We also offer end caps to complete the professional aesthetic.
Step Edge: Vision – Step (NLD)
NLD is a tile-in step edge incorporating Vision LED, CCT and RGB lighting systems. Designed to emphasise and accentuate each individual stair, illuminating the riser below to create a stunning stair case. Supplied in anodised Matt Silver finish with frosted polycarbonate diffuser for optimum light dispersion. Available in 9mm or 11mm depths and a standard length of 2.8m. We also offer end caps to complete the professional aesthetic.
Skirting: Vision – Skirting (KLD)
A retrofit aluminium skirting profile incorporating Vision LED, CCT and RGB lighting systems. Designed to create a border of low-level light which encapsulates the room. Supplied in anodised Matt Silver and Brushed Silver finishes with frosted polycarbonate diffuser for optimum light dispersion. Available in 100mm height and a standard length of 2.8m. We also offer end caps to complete the professional aesthetic.
LED System
Vision offers a range of premium profiles for commercial and domestic applications, designed to protect and inspire with variable mood accents.
The range is specifically designed to accept universal LED systems and RGB for steps, listello, edges and skirting offering unlimited freedom of design.
Safe and secure with 12V IP65 protection class as standard and premium 4.8W or 9.6W 120 LED’s per metre. Available in 4000K, or to achieve the optimal effect, our CCT option offers 3000K, 4000K and 6000K in a single length.
RGB system
This dynamic system offers a range of mood lighting powered by 12V IP65 protection, the 60 LED per metre powers varying colours with remote colour changing and dimming within a maximum of 4 Zones. RGB is 14.4W per metre and cuttable every 50mm.
Safety
All LEDs, drivers and components are CE-marked and tested to the following EN standards:
- EN 55015:2013
- EN 61547:2009
- EN 61000-3-2:2014
- EN 61000-3-3:2013
Drivers
Selecting the right driver is easy – use the below formula to find the best option for your installation:
Total Power (W) = Length of LED x Power Rating of LED (W)
For example, 5 metres of Vision 9.6W LED tape uses a total of 48W. This installation will need to use a driver with a rating of at least 50W. The perfect option would be our 50W LED driver LDD50.
Remote control options
Need more control? Vision RGB is compatible with single and multi-zone remote control, all you need is a receiver and remote-control handset. Why not go one step further and connect Vision RGB to a Smart driver and have ‘Alexa’ control your lighting.
Vision Smart LED Drivers can be used to control Vision LED lights with a compatible smart speaker or smart hub. This allows the user to turn the light on and off, adjust brightness and change the colour of the light using their voice or smartphone.
Dotless Flexible LED Tape
A flexible strip of continuous lighting with 144 LED’s per metre.
Cutting intervals are at a handy 21mm with a 2m power lead and micro connector.
Available in natural white and come in 1m, 2m or 3m coils. These tapes are compatible with our standard drivers.
EyeLEDS
EyeLEDs are an individual, recess mounted LED units which can be used to accentuate your installation. Compatible with our standard LED drivers and available in 3 colour temperatures – Cool, Natural and Warm White.
Overview – What you need
- Lighting System
- Driver
- Receiver (optional)
Installation
All vision products are designed to be easy to install and to work together seamlessly. Please consult the below overview for more information on the installation process.
